CV 3-200/SP5 Voltage Transducer Flux Gate, Vpn = 140V RMS, 10V output, +/- 15/24VDC supply, 2.5kV Isolation

Features

• Bandwidth DC to 700kHz
• Closed loop transducer using Flux Gate
• Compact and versatile
• Panel Mount
• Insulated plastic case recognized according to UL 94-V0

Advantages

• Very good linearity
• High accuracy
• Low temperature drift
• Wide frequency bandwidth
• Very low insertion losses
• High immunity to external interference
• Voltage overload capability
• Low power consumption

Applications

• Railway substation or locomotive
• High Frequency Drives
• AC variable speed drives and servo motor drives
• Static converters for DC motor drives
• Battery supplied applications
• Uninterruptible Power Supplies (UPS)
• Switched Mode Power Supplies (SMPS)
• Power supplies for welding applications
• Water Treatment Electronics
