DPT 611 115 AC Current Transducer - Class 1, 0-1A/1-5A True RMS Measurement, Self-Powered, 2x4-20mA Outputs for Industrial Automation & Energy Monitoring (50/60Hz)
DPT 611 115 AC Current Transducer - Class 1, 0-1A/1-5A True RMS Measurement, Self-Powered, 2x4-20mA Outputs for Industrial Automation & Energy Monitoring (50/60Hz)

DPT 611 115 AC Current Transducer - Class 1, 0-1A/1-5A True RMS Measurement, Self-Powered, 2x4-20mA Outputs for Industrial Automation & Energy Monitoring (50/60Hz)

$252.45 $459 -45%

Free shipping on all orders over $50

7-15 days international

7 people viewing this product right now!

30-day free returns

Secure checkout

39969582

Guranteed safe checkout
amex
paypal
discover
mastercard
visa
apple pay

DESCRIPTION

Iskra Doo DPT 611-115, AC Current Transducer, Class 1, 0-1Amp (or 1-5 Amp) 50/60Hz True RMS Measurement, Self Powered, 2 x 4-20mA Outputs

  • Class 1 (EN 60688)
  • Dual 4-20mA analogue outputs
  • Average RMS values of voltage
  • Self Powered

Features :

  • Measurement of up to 6 Amp AC

  • Accuracy class 0.5

  • Input frequency 50/60Hz
    Specification
    Iskra Doo Part NumberDPT 611-115
    FunctionsSingle Phase AC Current Transducer
    Supply VoltageSelf Powered
    Nominal Measurement Range0-1 Amp Default (0-5 Amp Via Software)
    OutputDual 4-20mA Outputs
    AccuracyClass 1
    Battery BackupN/A
    Isolation3.5kV
    CommsUSB
    Weight340g
    Enclosure MaterialUL94
    Factory Pack Qty1
    EU Directives

    N/A

    Safety

    Protection Class II

    600V rms, installation category II

    300V rms, installation category III

    Pollution Degree 2 in compliance with SIST EN 61010-1:2002

    Enclosure MaterialPC/ABS non combustable-self-extinguishability, complying with UL 94 V-0
    Enclosure ProtectionIP20



    Shock Withstand300g 8ms Pulse . 6 Shocks in each of 3 axes
    Vibration Withstand0.7g, 3...100Hz, 1oct/min 10 cycles in each of three axes
    Operating Temperature-20 →+70 °C



    Datasheet
