Fluke I5S 5A AC Current Probe (Model 2508467) - Professional Electrical Testing Tool for HVAC, Industrial Maintenance & Home Electrical Safety Checks
Fluke I5S 5A AC Current Probe (Model 2508467) - Professional Electrical Testing Tool for HVAC, Industrial Maintenance & Home Electrical Safety Checks

Fluke I5S 5A AC Current Probe (Model 2508467) - Professional Electrical Testing Tool for HVAC, Industrial Maintenance & Home Electrical Safety Checks

$869.55 $1581 -45%

Free shipping on all orders over $50

7-15 days international

22 people viewing this product right now!

30-day free returns

Secure checkout

56708492

Guranteed safe checkout
amex
paypal
discover
mastercard
visa
apple pay

DESCRIPTION

(item no. 2508467)

Product Overview

Expand the use of your Fluke 430 series power quality tool with this 5 A ac current clamp, specially configured to provide low current accuracy while taking measurements on secondary current transformers.

Features

  • Low level current clamp measures up to 5 A ac
  • Compact shape makes transporting and storing convenient; the clamp measures only 116 x 43 x 23 mm (4. 6 x 1.7 x .9 inches)
  • Take accurate readings without breakings the circuit
  • CAT III 600 V (For insulated conductors only)



Specifications: Fluke i5S AC Current Clamp

Specifications
Nominal current range5 A
Continuous current range10 mA to 6 A
Maximum Non-Destructive Current70 A
Lowest measurable current10 mA
Basic Accuracy48 Hz to 65 Hz
10 mA to 1 A1% + 5 mA
1 A to 5 A1%
Useable frequency40 Hz to 5 kHz
Output level(s)400 mV/A
Input Load Impedance> 1 MΩ in parallel with up to 47 pF
Crest Factor≤ 3, add 0.7% to accuracy
Safety Specifications
SafetyCAT III 600 V per IEC/EN61010-1, Pollution Degree 2
Maximum voltage600 V AC
Mechanical and General Specifications
Warranty1 year
Maximum conductor diameter15 mm
Output cable length2.5 m
BNC AdapterYes
BNC to banana adapter includedNo



 Manuals
