DS72/50A/60mV Moving Coil Ammeter - 50A DC Current Meter with 60mV Shunt Connection for Solar Panels, Battery Monitoring & Industrial Electrical Systems
DS72/50A/60mV Moving Coil Ammeter - 50A DC Current Meter with 60mV Shunt Connection for Solar Panels, Battery Monitoring & Industrial Electrical SystemsDS72/50A/60mV Moving Coil Ammeter - 50A DC Current Meter with 60mV Shunt Connection for Solar Panels, Battery Monitoring & Industrial Electrical Systems

DS72/50A/60mV Moving Coil Ammeter - 50A DC Current Meter with 60mV Shunt Connection for Solar Panels, Battery Monitoring & Industrial Electrical Systems

$38.22 $69.5 -45%

Free shipping on all orders over $50

7-15 days international

15 people viewing this product right now!

30-day free returns

Secure checkout

65515404

Guranteed safe checkout
amex
paypal
discover
mastercard
visa
apple pay

DESCRIPTION

Rishabh DS72/50A/60mV, Moving Coil Ammeter 50Amp for 50A/60mVDC Shunt Connect

Features

  • Adjustable Display Scaling
  • PC 94 UL V0
  • For robust Measurement
  • Each unit needs just 72 x 72mm Panel Space
  • 65mm Depth
    Specification
    Rishabh Part NumberDS72/50A/60mV
    Nominal Measurement Range0 - 50 Amp DC
    Shunt Input0-60mV Unipolar
    Maximum Measurement Range100 Amp DC
    Over RangeIpn x 2
    Operating Temperature0 - 50°C
    Frequency15...100Hz
    Safety RatingIP52 case, IP20 terminals with back cover
    Termination StyleScrew
    Mounting Style 72 x 72mm Panel Mount
    Case MaterialPC - UL 94 V0
    Weight320g
    Factory Pack Qty1



    Datasheet
