Solid State Relay Single Phase 25A 4-32VDC Control 24-280VAC Load with LED Indicator - High Surge Protection for Industrial Automation & HVAC Systems
Solid State Relay Single Phase 25A 4-32VDC Control 24-280VAC Load with LED Indicator - High Surge Protection for Industrial Automation & HVAC Systems

Solid State Relay Single Phase 25A 4-32VDC Control 24-280VAC Load with LED Indicator - High Surge Protection for Industrial Automation & HVAC Systems

$50.88 $92.51 -45%

Free shipping on all orders over $50

7-15 days international

28 people viewing this product right now!

30-day free returns

Secure checkout

90692190

Guranteed safe checkout
amex
paypal
discover
mastercard
visa
apple pay

DESCRIPTION

Crydom CWD2425, Solid State Relay, Single Phase 4-32VDC Control, 25A, 24-280VAC Load. High surge w/LED Indicator

  • Ratings from 25A to 125 Amp @ 24-280VAC
  • SCR output for heavy industrial loads
  • Zero voltage or instantaneous turn-on outputs
  • UL/CSA/VDE Approved, CE Compliant to EN60950-1
  • Improved SEMS screw and washer
  • Redesigned housing with anti-rotation barriers
  • AC & DC control types
  • Direct bond copper substrate
  • EMC compliant to Level 3
  • Direct power lead frame
  • Epoxy free design
Spec
Crydom Part NumberCWD2425
Switching TypeZero Crossing
ROHSYes ()
Control Voltage4-32VDC
Load Current 25 Amp (rms)
Surge Capability (16.6ms)600 Amp (peak)
Special FeatureLED Status Indicator, High Surge
Mounting StylePanel Mount
Load Voltage Range24-280VAC
EMC CompliantLevel 3
Termination StyleScrew
Unit Weight75g
Factory Pack Qty20



Datasheet
Notifications

Please note Changes from Gen 3 to Gen 4 (current) package design

Equivalent

for stocked equivalent

App Notes
Heatsink
