CWU2450P Solid State Relay 50A 24-280VAC Single Phase SSR with 20-48VDC/20-280VAC Control - High Surge Rating, Status LED & Overvoltage Protection - Perfect for Industrial Automation, HVAC Systems, and Power Control Applications
CWU2450P Solid State Relay 50A 24-280VAC Single Phase SSR with 20-48VDC/20-280VAC Control - High Surge Rating, Status LED & Overvoltage Protection - Perfect for Industrial Automation, HVAC Systems, and Power Control Applications

CWU2450P Solid State Relay 50A 24-280VAC Single Phase SSR with 20-48VDC/20-280VAC Control - High Surge Rating, Status LED & Overvoltage Protection - Perfect for Industrial Automation, HVAC Systems, and Power Control Applications

$61 $110.92 -45%

Free shipping on all orders over $50

7-15 days international

19 people viewing this product right now!

30-day free returns

Secure checkout

13810892

Guranteed safe checkout
amex
paypal
discover
mastercard
visa
apple pay

DESCRIPTION

Crydom CWU2450P, Solid State Relay, Single Phase 20-48VDC or 20-280VAC Control, 50A, 24-280VAC Load, High Surge Rating w/status LED + Overvoltage Protection

Features

  • Ratings from 25A to 125 Amp @48-600VAC
  • SCR output for heavy industrial loads
  • Zero voltage or instantaneous turn-on outputs
  • UL/CSA/VDE Approved, CE Compliant to EN60950-1
  • Improved SEMS screw and washer
  • Redesigned housing with anti-rotation barriers
  • AC & DC control types
  • Direct bond copper substrate
  • EMC compliant to Level 3
  • Direct power lead frame
  • Epoxy free design
Spec
Crydom Part NumberCWU2450P
Switching TypeZero Crossing
ROHSYes ()
Control Voltage20-48VDC or 20-280VAC
Load Current 50 Amp (rms)
Surge Capability 850 Amp (peak)
Special FeatureLED Status Indicator, High Surge, Internal Over Voltage Protection
Mounting StylePanel Mount
Load Voltage Range24-280VAC
EMC CompliantLevel 3
Termination StyleScrew
Unit Weight75g
Factory Pack Qty20



Datasheet
Notifications

Please note Changes from Gen 3 to Gen 4 (current) package design

Equivalent
See , , for stocked equivalent (no overvoltage protection).
App Notes
Heatsink
