90A Solid State Relay CWU4890P - Single Phase 20-48VDC/20-280VAC Control, 48-530VAC Load with High Surge Rating | Status LED & Overvoltage Protection | Ideal for Industrial Automation, HVAC Systems & Power Control Applications
90A Solid State Relay CWU4890P - Single Phase 20-48VDC/20-280VAC Control, 48-530VAC Load with High Surge Rating | Status LED & Overvoltage Protection | Ideal for Industrial Automation, HVAC Systems & Power Control Applications

90A Solid State Relay CWU4890P - Single Phase 20-48VDC/20-280VAC Control, 48-530VAC Load with High Surge Rating | Status LED & Overvoltage Protection | Ideal for Industrial Automation, HVAC Systems & Power Control Applications

$106.88 $194.33 -45%

Free shipping on all orders over $50

7-15 days international

25 people viewing this product right now!

30-day free returns

Secure checkout

25795564

Guranteed safe checkout
amex
paypal
discover
mastercard
visa
apple pay

DESCRIPTION

Crydom CWU4890P, Solid State Relay, Single Phase 20-48VDC or 20-280VAC Control, 90A, 48-530VAC Load, High Surge Rating w/status LED + Overvoltage Protection

Features

  • Ratings from 25A to 125 Amp @48-600VAC
  • SCR output for heavy industrial loads
  • Zero voltage or instantaneous turn-on outputs
  • UL/CSA/VDE Approved, CE Compliant to EN60950-1
  • Improved SEMS screw and washer
  • Redesigned housing with anti-rotation barriers
  • AC & DC control types
  • Direct bond copper substrate
  • EMC compliant to Level 3
  • Direct power lead frame
  • Epoxy free design
Spec
Crydom Part NumberCWU4890P
Switching TypeZero Crossing
ROHSYes ()
Control Voltage20-48VDC or 20-280VAC
Load Current 90 Amp (rms)
Surge Capability 1290 Amp (peak)
Special FeatureLED Status Indicator, High Surge, Internal Over Voltage Protection
Mounting StylePanel Mount
Load Voltage Range48-660VAC
EMC CompliantLevel 3
Termination StyleScrew
Unit Weight75g
Factory Pack Qty20



Datasheet
Notifications

Please note Changes from Gen 3 to Gen 4 (current) package design

Equivalent
See , , for stocked equivalent (no overvoltage protection).
App Notes
Heatsink
