Infineon DD89N14K Dual Diode Module
Features
- Pressure Contact Technology
- Electrically insulated base plate
- Very low forward voltage drop
- Very low leakage current
- International standard package
- 3000V Isolation
- 20mm Base Width
Applications
- Power Supplies
- Rectifier for drives applications
- Uncontrolled Rectifiers
- Rectifiers for UPS
- Battery Chargers
- Filed Supply for DC Motors
- DC supply for PWM inverter
Specification
infineon Part Number | DD89N14K |
Vrrm | 1400V |
Diode Configuration | Dual Diode Module |
IF(av) @ 100 Deg C | 89 Amp |
Package Size | W:20mm L:94mm D:30mm |
Itsm | 2.8 kA |
VF(to) | 0.75V |
Tj(max) | 150°C |
rF | 0.215mΩ |
Terminals | M10 Bolt |
Hole Centres | 80mm x 38mm (M6) |
Gate Terminals | N/A |
R th(j-c) | 0.225°C/W |
R th(c-h) | 0.10°C/W |
Weight | 160g |
Mounting Torque | 4 Nm (4 Nm Terminals) |
Factory Pack Qty | 15 |
Certification | UL Listed, ROHS |
Infineon Headquarters | Germany |
Datasheet
Alternatives
See for Pressure Contact, and or for Solder Bonded Devices
