| Videoscope probe |
| Length | 1.2 meter (3.94 feet) |
| Type | Detachable, semi-ridged, waterproof, immersible to 1 meter or more in depth |
| Diameter | 8.5 mm (0.33 inches), optional 3.8, 5.5 and 9 mm probes available |
| Material | Elastomer coated steel |
| Lighting | Adjustable LED, on front, one side |
| Illumination | 53 Lux |
| Up is Up™ Technology | Appropriate image display, regardless of the orientation of the probe, 8.5 MM, 1.2 M probe only |
| Camera |
| Dual view camera, forward and side |
| Resolution | 1200 x 720 (864,000 pixels) |
| Still image format | JPG |
| Video Recording Format | AVI |
| Video Output Format | MPEG compression |
| Digital zoom | Adjustable from 1x to 8x zoom |
| Field of view | 68° |
| Depth of field | 25 mm to infinity |
| Video resolution | 720 p |
| Minimum focus distance | 10 mm |
| Focus Type | Fixed |
| Rotation | 180° |
| Streaming video | Via HDMI and Fluke Connect™ |
| LCD Screen |
| Touch Screen | Capacitive touch screen |
| Size | 7 inch (17.79 cm) |
| Refresh rate | 30 hz |
| UpisUp™ technology | Real-time upright adjustment for image |
| LED backlight | Adjust display brightness for optimal viewing |
| Communication |
| Wireless Interface | WiFi 802.11b/g/n, Range: 33 feet (10.06 meters) |
| Data Transfer | USB and micro HDMI cable |
| Fluke Connect™ | Save and share images directly from the Videoscope. Attach images or video to an asset record or work order. |
| Instant upload to the cloud | Yes, with Fluke Connect™ |
| General Features |
| Color palettes | Visible light, grayscale or inverted |
| Internal memory | 6 GB |
| Physical buttons | Intuitive, easy to navigate button technology, 4 functional keys, 4 navigational, one capture or select button |
| Carrying case | Protective EVA case |
| Strap | Hand strap and neck strap |
| Power adapter | AC adapter/battery charger input |
| Battery | 6400mAh 3.7 volt rechargeable internal li-ion battery |
| Battery life | 3 hours at 50 % LED brightness |
| Dimensions | 6.98 x 8.85 inches (17.73 x 22.48 cm) |
| Weight | 1.95 lbs (0.88 Kg) |
| IP Rating |
| Tablet | IP54, dust protected and protected against water projected from a nozzle |
| Probe | IP68, dust tight and immersion of 1 meter or more depth |
| Drop Test | 2 meter (6.56 feet) |
| Operating temperature | 0 °C to 45 °C (32 °F to 113 °F), 50 °C (113 °F) for less than 10 minutes |
| Storage temperature | -40 °C to 60 °C (-40 °F to 140 °F) |
| Operating humidity | 90 % at 35 °C (95 °F)
75 % at 40 °C (104 °F)
45 % at 50 °C (122 °F) |
| Warranty | 2 years |
Probe Accessories Specifications
| Probe | Views | Up-is-Up | DS701-Display resolution | DS703-Display Resolution | Imager Resolution |
| Standard Probe. 8.5mm 1.2M | Dual | Yes | 800 X 600 | 1200 X 720 | 1280 x 720 |
| 3.8mm , 1M | Forward | X | 800 X 600 | 1200 X 720 | 720 x 488 |
| 8.5mm, 3M | Dual | Yes | 800 X 600 | 1200 X 720 | 1280 x 720 |
| 5.5mm, 1M | Dual | X | 800 X 600 | 1200 X 720 | 640 x 480 |
| 8.5mm UV, 1M | Dual | X | 800 X 600 | 1200 X 720 | 1280 x 720 |
| 9mm, 20M | Forward | X | 800 X 600 | 1200 X 720 | 720 x 488 |
