Schurter CE20.6100.151, IEC Appliance Inlet C14/M with Filter, Fuseholder 2-pole 5 x 20 mm
Features
- Panel Mount : Screw-on mounting from front side
- 4 Functions : Appliance Inlet Protection class I, EMC Line Filter Line Switch 2-pole, Fuseholder for fuse-links 5 x 20 mm 2-pole
- Line filter in standard and medical version
- Quick connect terminals 6.3 x 0.8 mm
Characteristics
- Compact design with optimal shielding
- All single elements are already wired
- Plug removal necessary for fuse-link replacement
- With EMC-shield
- Suitable for use in equipment according to IEC/UL 60950
- Suitable for use in medical equipment according to IEC/UL 60601-1
Medical Version
NOTE Requires 4305.0001,4305.0006,4305.0011,or 4305.0016 Fuse Drawer
Specification
Schurter Part Number | CE20.6100.151 |
Rated Voltage | 250V |
Rated Current | 2A |
Filter Stages | 1 Stage Standard |
Operating Temperature | -25°C to 85°C |
Filter Type | Differential and Common Mode |
Fuse Holder | 2 Pole |
Line Switch | 2 Pole |
Mounting
| Panel Mount |
Material | Nickel Plated Steel |
Termination Style | C14 Male to Quick Connects |
Weight | 260g |
Factory Pack Qty | 1 |
Protection Class | From front side IP 40 acc. to IEC 60529 |
Isolation | 1.7kV |
VDE/UL/CSA/ROHS | Yes |
Datasheet
